Eco-Lite Tube Rings

The Eco-Lite Tube Rings from Rouz Astro are a series of tube rings designed with simplicity and practicality in mind, offering a budget-friendly solution for telescope mounting. They cover all the essential features needed for telescope support and provide a lightweight, durable alternative to traditional metal rings. With a focus on ease of use and versatility, they are suitable for a variety of telescopes and can be customized to fit different specifications.

ECO-LITE Tube Rings – Rouz Astro

They are constructed from a carbon fiber composite material, which gives them a significant weight advantage over traditional cast metal rings. They are typically about one-third the weight of comparable metal options, which can enhance the overall performance of your telescope and mount by reducing the load placed on the system. Despite the lightweight nature, they retain a high level of strength and durability.

They feature an integrated bottom spacer, which raises the telescope slightly to create additional space for focusers, improving ease of use and functionality. This design enhances the overall performance of the telescope by ensuring more room for adjustments, especially when using larger or more complex accessories. The split design allows them to wrap around the telescope tube, providing extra grip and securing the telescope firmly in place.

The modular nature of the design also means that they are compatible with various lightweight dovetails and handles, giving users flexibility when setting up their systems. They are also designed with a single mounting bolt, making it simple to mount them on any compatible dovetail.

They are made using a composite of high-modulus carbon fiber and polymers that are fused at high temperatures, ensuring durability without relying on adhesives like glue or epoxy. This process results in a robust, high-quality product capable of withstanding the stresses placed on it during use. All of the bolts are threaded into stainless steel receptors, adding to the strength and longevity of the them.

The composite material used in them offers excellent resistance to UV light, water, and extreme temperatures, withstanding temperatures as high as 66°C (150°F). This makes them suitable for use in a variety of environmental conditions, providing long-lasting performance in both hot and cold climates.

They come in a range of sizes to accommodate various telescope models. The sizes available range from small 60mm rings suitable for smaller telescopes, up to 222mm rings designed for larger telescopes like the GSO 8" f/5 Newtonian. Custom sizing options are also available, allowing users to contact Rouz Astro for a more precise fit based on their specific needs.

Each pair of them is designed with a tolerance of +/- 2.5mm (0.1in.), allowing for minor adjustments to ensure a perfect fit for different tube diameters. They are sold as a pair, though additional single rings can be purchased separately for specialized setups or heavier payloads.

Specifications

• Material: High-modulus carbon fiber composite and polymers
• Ring Width: 20mm (0.75in.)
• Threads: Stainless steel M6
• Weight per Ring: Between 100g and 250g, depending on size
• Temperature Resistance: Can withstand temperatures up to 66°C (150°F)
• Water and UV Resistance: Built to resist damage from exposure to water and UV light
• Mounting: Single bolt for bottom mounting, three attachment points on top ring
• Adjustability: Size tolerance of +/- 2.5mm (0.1in.)
• Felt-Lined Interior: Premium non-woven needled fabric for protection
• Sold As: A pair of rings, with additional ring options available for larger payloads


They provide an affordable and efficient solution for telescope mounting. With a lightweight, modular design and a range of customizable options, they cater to a wide variety of telescope sizes and configurations. Whether you're looking for a simple mounting solution or need additional support for larger setups, the Eco-Lite Tube Rings offer a practical and cost-effective choice for both novice and experienced astronomers.

This no-frills line of tube rings covers all the essentials while keeping it budget-friendly

For users requiring extra support or looking to carry additional accessories, the rings offer the option to add a top or bottom dovetail. These dovetails come in several configurations, including lightweight carbon fiber and aluminum options, and can support loads of up to 20lbs (9kg). These dovetails are sold separately and are available in different lengths to suit various needs, including options for both Losmandy and Vixen dovetail systems.

They are designed with ease of installation in mind. Each ring features a single bolt for bottom mounting, which simplifies the mounting process. Additionally, the top ring is equipped with three attachment points, allowing users to attach brackets and other accessories to further customize their setup.

The felt-lined interior of them ensures that the telescope tube is securely held without causing damage to the surface. The felt is made from a premium non-woven needled fabric, providing a soft, protective cushion that minimizes the risk of scratches or other surface damage during use.

For users who need a more heavy-duty option, they are available with additional rings, increasing the number of attachment points for higher payloads. These heavy-duty configurations provide added security and stability for larger telescopes or setups requiring additional equipment.

They are designed to enhance the overall performance of a telescope mount by reducing the overall weight of the system, improving ease of adjustment, and increasing the stability of the telescope. By using carbon fiber composite materials and an efficient, lightweight design, they help reduce the stress placed on the mount, leading to improved tracking and image quality during use.

The reduced weight of them also means that the telescope can be more easily transported and handled, making them a good choice for both amateur and professional astronomers who need to move their equipment frequently. The modular design, combined with the option to add different dovetail types and mounting accessories, makes them a versatile solution for various telescope configurations.
